DC3200 Bag Filter Dust Collector

  • 1
  • 2

Brand Name : Sooannas

Model Number : SAFD-01

Certification : CE ISO

Place of Origin : China

MOQ : 1 Set

Price : CN¥192,918.00-CN¥341,925.00

Payment Terms : L/C, T/T, Western Union, MoneyGram

Delivery Time : 3 months after deposit

Packaging Details : Standard containers loading, nude packing for filter body, thin film packing for main parts, carton packing for filter bags, accessories etc.

Supply Ability : 280 Set/Sets per Year

Dust out : <10 mg/Nm3

Weight : Customized

Minimum Particle : 5 Micron

After-sales Service : Field installation, commissioning and training

OEM service : Yes

Dust collector type : Baghouse dust collector

Voltage : According to client's country voltage

Feature : Critical cleaning / Residue free

Model Numbe : DMC series

Cleaning type : Clean-In-Place (CIP)

Air consumption : 1.5-7.5

Contact Now

Product Description

DMC dust collector makes the compressed air as driving force for cleaning air, uses pulse injection organization releases the compressed air instantly and induces the severalfold secondary air into the filter bag at high speed to make the bags expand rapidly so as to impact,shake and reverse flow to clean the dust.

The products are a series of products with the filter bag for a set number 12, mainly in 24 bags, 36 bags, 48 bags, 60 bags, 72 bags, 84 bags, 96 bags, 112 bags, 120 bags.

Main Features for Dust Collector

1) The dust removing efficiency is over 99.9% and emission concentration is less than 30mg/Nm3.
2) High density dust air below 1000mg/Nm3 is available.
3) It has stable and reliable performance, high degree of automation and low investment.
4) Wear resistance and Corrosion resistance
5) High temperature resistance and Long operating life
6) Safe and reliable operating performance stable and Small footprint and low cost
7) Simple operation and Easy administrate and without operation cost

DC3200 Bag Filter Dust Collector

Product Details

DC3200 Bag Filter Dust Collector

Baghouse Structure

DC3200 Bag Filter Dust Collector

Technical Parameters for Dust Collector

Model JBQM JBQM JBQM JBQM JBQM JBQM JBQM JBQM JBQM
32-3 32-4 32-5 32-6 64-4 64-5 64-6 64-7 64-8
Technical parameter
Air volume(m³/h) 6690 8930 11160 13390 17800 22300 26700 31200 35700
Total filter area(m²) 93 124 155 186 248 310 372 434 496
Chamber(pcs) 3 4 5 6 4 5 6 7 8
Quantity of filter bag(pcs) 32 64
Total quantity filter bag(pcs) 96 128 160 192 256 320 384 448 512
Pulse Valve Quantity(pcs) 3 4 5 6 4 5 6 7 8
Specitication(inch) 1/½″ 2/½″
Specification of filter bag(D×Lmm) ∅130×2450
Filter material Based on flue gas properties
Filtration speed(m/min) 0.8~2.0(Adjustable)
Negative pressure(pa) ≤6000
Resistance(pa) 1470~1770
Inlet dust concentration(g/Nm³) <200 <1000
Blowing pressure(Mpa) 0.5~0.7
Compressed air consumption(Nm³/min) 0.27 0.37 0.46 0.55 1.2 1.5 1.8 2.1 2.4
Air locking unit Adjustable
Screw converyor NO

Adjustable
Area of heat preservation(m²) 26.5 34 41 48.5 70 94 118 142

176

Model JBQM JBQM JBQM JBQM JBQM JBQM JBQM JBQM JBQM JBQM JBQM JBQM
96-4 96-5 96-6 96-7 96-8 96-9 96-10B 96-12B 96-14B 96-16B 96-18B 96-20B
Technical parameter
Air volume(m³/h) 26800 33400 40100 46800 53510 60100 66900 80400 93750 107150 120500 133900
Total filter area(m²) 372 465 557 650 744 836 930 1023 1209 1395 1581 1767
Chamber(pcs) 4 5 6 7 8 9 10 12 14 16 18 20
Quantity of filter bag(pcs) 96
Total quantity filter bag(pcs) 384 480 576 672 768 864 960 1152 1344 1536 1728 1920
Pulse Valve Quantity(pcs) 4 5 6 7 8 9 10 12 14 16 18 20
Specitication(inch) 2/½″
Specification of filter bag(D×Lmm) ∅130×2450
Filter material Based on flue gas properties
Filtration speed(m/min) 0.8~2.0(Adjustable)
Negative pressure(pa) ≤6000
Resistance(pa) 1470~1770
Inlet dust concentration(g/Nm³) <1300
Blowing pressure(Mpa) 0.5~0.7
Compressed air consumption(Nm³/min) 1.2 1.5 1.8 2.1 2.4 2.7 3 3.4 4.2 4.8 5.4 6
Air locking unit Adjustable
Screw converyor Adjustable
Area of heat preservation(m²) 110 120 130 140 150 160 175 210 215 280 315 350

Case Presentation

DC3200 Bag Filter Dust Collector

Order Steps

DC3200 Bag Filter Dust Collector

Our Services

Product Tags:

DC3200 Bag Filter Dust Collector



DC3200 cement silo dust collector



5 Micron Bag Filter Dust Collector


We provide 12months quality warranty to make sure your machine well runs consistently.
1) Pre-sale services:
a. Professional engineer design layout drawing for you
b. Recommend most suitable equipment according to your factory situation.
2) During-sale services:
a. Pre-check and accept products before delivery
b. Send technicians to the jobsite for guiding the installation and adjustment
c. Training operators and finishing the check to satisfy factory situation.
3) After-sale services:

a.Common problem can be solved through web in 24 hours,complex problem can be reacted

immediately in 24 hours and solved as soon as possible
